LIGHT HEAD
- Power: 72W SPOT
- Light angle: 8°
- Colour temperature: 6500 °K
- Luminance: 7444lm – 100%, 3722lm – 50%, 1488lm – 20%
- Piezo switch for power adjustment: 100% – 50% – 20% – OFF
- Battery indicator: displays the current battery charge level
- E/O cord: 45cm or according to customer requirements
- Head dimensions (L x D): 10,5 cm x 6,3 cm
- Made of: anodised aluminium, Delrin
- Type of handle: Goodman
- Max. operating depth: 150m
The 72W LED SPOT diving light head features a focused 8° beam angle, delivering a powerful and concentrated light for deep-sea exploration. This narrow beam is ideal for penetrating dark or murky waters, ensuring precise visibility. With high brightness and a cool color temperature, it offers excellent illumination, resembling natural daylight underwater.
Thanks to the built-in touch PIEZO switch in the head, the user has the ability to adjust the power in 3 steps: 100% – 50% – 20% – OFF. This allows the amount of light to be adapted to the underwater conditions without losing contact with the light while reducing the power.
Built from durable materials like anodized aluminum and Delrin, it is designed to handle depths up to 150m. Key advantages include its robust construction, efficient battery management with an indicator for real-time charge status, and a Goodman handle, ensuring stable and comfortable hands-free use.
The LED indicator, labelled „LED Indicator,” is located on the right side of the head. This indicator shows the battery’s performance status and provides real-time information about the remaining battery capacity.
When the battery is turned on, the LED indicator displays one of the following statuses:
- Green (steady): 100% – 16% charge remaining
- Red (steady): 15% – 6% charge remaining
- Red (flashing): 5% – 0.1% charge remaining
There are two independent LEDs module.
„Angles of light” indicator shows a different angle of light beam. The indicator is located on the right side of the head. The modes lights work both together or separately. LED diode provides information on the current angle of light.
It lights in one of the following modes:
- green – 35 Watt/ 12°
- red – 40 Watt/ 120°
- yellow – 75 Watt both channels of driver together
You can switch between modes by using switch on/off.
When you turn the light off, you have 5 seconds to turn it on again then the mode changes. If you turn it off forlonger period (more than 5 seconds), the light will work in it’s first mode (35 Watt, 12°).
The battery indicator shows the level of the battery charge. Labelled „LED indicator”. The LED indicator is located on the rightside of the head. The LED light indicates the battery performance status and providesinformation on the current battery level.
When the battery is switched on, the indicator lights in one of thefollowing modes:
- green, continuous: 100 % – 15 % of charge capacity
- red, continuous: 15 % – 5 %
- red, intermittent: 5% – 0,1 %
